At Flexible Circuit Technologies, we pride ourselves on guiding customers on the most complex of design challenges to provide the most reliable and cost-effective designs. Rigid flex circuits can be designed to meet highly complex and unimaginable configurations by utilizing both rigid and flexible substrates. Rigid flex circuit designs can incorporate any of the following:

Highly complex configurations
Controlled Impedance
High layer count
Reduced interconnections
High Density Applications – By eliminating interconnecting hardware, rigid flex can free up space allowing for higher connection density. More often than not, the rigid areas of a rigid flex circuit are utilized for high density SMT device population. The flexible regions connecting the rigid areas allow the circuit to be formed into a 3-dimensional shape, with multiple interconnected rigid areas on different planes.

YS Rigid Flex PCB manufacturing capabilities overview

FQA
1. Rigid-flex PCB vs. rigid PCBs and flexible PCB, What are the differences?
As the name suggests, rigid-flex PCB is a mixture of rigid and flexible PCBs.
Rigid-flex PCBs combine the excellent qualities of both while eliminating many of their limitations.
Rigid-flex PCBs combine flex circuit design with rigid materials.

By layering the flexible PCB board inside the rigid printed circuit board material, the versatility of the flexible printed circuit is finally combined with the stability, strength, and circuit wiring density of the rigid printed circuit board.
This mixing opens possibilities for more complex and mechanically challenging rigid-flex PCB designs.

Rigid-flex PCB simplifies the electronic design by eliminating flexible cables, connectors, and discrete wiring.
Its electrical performance has been enhanced compared to its counterparts because the circuit is an integral part of the overall structure.
All electrical and mechanical connections are contained in the rigid-flex PCB, providing electronic designers with greatly improved service reliability and electrical performance.

Although the cost of rigid-flex PCBs is usually higher than flexible PCBs and rigid PCBs.
However, rigid-flex PCBs’ reliability, weight reduction, strength, and space-saving advantages are generally ideal in specific applications and are superior to any other electronic packaging technology.
Ultimately, rigid-flex PCB provides the best benefits of rigid PCBs and flexible PCBs in one solution.

2. How you work with YScircuit?
Step 1: Submit or Send your PCB files (Gerber) and requirements to sales@yscircuit.com, and our customer support will reply you within 2 hours.
Step 2: You will get the official quotation from YScircuit within 6 hours.
Step 3: Place your order and our enginner will review the Gerber and comforming you with the EQ, and then, the production will start.

Welcome to YScircuit!
